Laser Type | Fiber Lasers |
Laser Power | 30W |
Laser Wavelength | 1064nm |
Q-frequency | 20KHz~80KHz |
Divergence | 0.3mard |
Marking Range | 10*10mm to 300*300mm |
Minimum Line Width | 0.02mm |
Minimum Character | 0.15mm |
Marking Depth | 0~0.5mm |
Engraving Line Speed | ≤7000mm/s |
Repeatability Accuracy | ±0.001MM |
Beam Quality | M2: 1.2~1.8 |
Marking Format | Graphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date, Batchnumber, Serialnumber, Frequency, ext. |
Graphic Format Supported | bmp, jpg, gif, tga, png, tif, ai, dxf, dst, plt, etc. |
Working Voltage | 220V±10%/ 50Hz/ 4A |
Unit Power | <0.5KW |
Use of the Environment | Clean and Dust Free or Dust less |
Working Condition: Humidity | 5%-75%, Free of Condensed Water |
Laser Module Life | >100000 hours |
